Software Features

• Redundancy Protocol: Support STP/RSTP
• Multicast Support: Support IGMP Snooping VI
• VLAN: Support IEEE 802. IQ 4K VLAN, Port Isolation, Trunk Group Setting
• QOS:Support Port, .1Q, ACL, DSCP, CVLAN, SVLAN, DA, SA, Port Priority, QueueWeight
• Diagnostic Maintenance: Support port mirroring, Port Statistics, Cable Diagnostic
• Management Function: WEB, SNMPv1 , EEE, Green Ethernet
• Security: Broadcast/MuIticast Storm Protection, MAC filtering, MAC Constraint
• Advance Functions: Bandwidth Control(lngress and Egress Rate), Jumbo Frame,
• Firmware Online Upgrade, Configuration Backup

Physical Characteristics

• Housing: Aluminium case
• IP Rating: IP40
• Dimensions: 138mm x 108mm x 49mm (L x W x H)
• Installation: DIN Rail/Wall Mount

Ethernet Interface

ports

• RJ45 ports-ox 100/1 OOOBase-X SFP ports
• Pon Mode(Tx): Auto-Negotiation Speed
• Full/Half Duplex Mode
• Auto MDI/MDI-X Connection

Standards

• IEEE 802.3 for 10BaseT
• IEEE 802.3u for 100BaseT(X) and 100BaseFX
• IEEE 802.3ab for IOOOBaseT(X)
• IEEE 802.3z for 1 OOOBaseSX/LX/LHX/ZX
• IEEE 802.3x for flow control
• IEEE 802.1 D-2004 for Spanning Tree Protocol
• IEEE 802. lw for Rapid Spanning Tree Protocol
• IEEE 802. Ip for Class of Service
• IEEE 802. IQ for VLAN Tagging

• Packet Buffer Size: 2M
• Maximum Packet Length: Up to 9K
• MAC Address Table: 4K
• Transmission Mode: Store and Forward (full/half duplex mode)
• Exchange Property: Delay time: < 7gs Backplane bandwidth: 20G
• IGMP Group: 256
• VLAN ID Range: VID 1 to 4094

Environmental

Operating Temperature

to 750C

Operating Humidity

(non-condensing)

Storage Temperature

 -400C85cc

MTBF

 907 ,476 hours @ Telcordia SR-332 Standard

Heat Dissipation

34 BTU/h

Cooling: Passive Cooling, Fanless Design

Weight: 680G
