Houper One-Satellite modulated Optical Transmitter

Review (0)

$1,775.00

Tax Included

The Houper 2212 optical transmitter is engineered in accordance with CATV standards. It converts CATV RF amplitude signals into optical signals at 1310nm/1550nm and subsequently transmits these signals to the optical node within an HFC network via single-mode optical fiber. This device is primarily utilized for the transmission of television signals in medium-sized networks and offers versatility in its applications. High-power optical amplifiers facilitate the deployment of fiber-to-the-home (FTTH) networks.The HOUPER 2212 is outfitted with a robust and stable optical output power circuit, along with a thermoelectric cooler for the pump laser, ensuring optimal performance. Its thoughtfully designed cooling structure, combined with an intelligent temperature control fan, minimizes power consumption. This makes it an excellent option for establishing signal transmission in CATV secondary networks.

Performance Features

Utilizing high-performance DFB lasers from renowned international brands ensures narrow spectral lines, excellent linearity, and substantial output power.

The sophisticated multi-frequency RF predistortion technology leverages automatic RF power processing to optimize the drive levels, maintaining the C/CTB, C/CSO, and C/N specifications at their ideal values.

A 32-bit ARM processor efficiently manages the operational status of each module while accurately monitoring and controlling all operating parameters.

The laser temperature stabilization circuit (ATC) and optical power output stabilization circuit (APC) guarantee optimal laser functionality.

The device operates within a bandwidth of 47-862MHz, with the option for customization up to 1000MHz.

A dual-module design is incorporated to enhance features such as light emission, EDFA, light collection, RF switching, and additional functionalities.

The modular architecture facilitates easy expansion of equipment capabilities and simplifies maintenance.

A standard network management interface is compatible with the SNMP network management protocol.

The power supply supports dual power hot backup, featuring a snap-type fixture that allows for one-touch operation. It is user-friendly and securely fixed, with voltage options of 220V, 110V, or 48V available.
