Product Parameters:
44 Signal Inputs (40 Analog + 4 Digital):
32 MIC/Line inputs,
2 x 3.5mm stereo inputs,
3.5mm stereo headphone input,
Digital input: sound card, MP3, AES.
20 Signal Outputs:
Main L/R output,
14 AUX outputs,
1 earphone monitoring output,
AES output.
Signal Remote Expansion:
Connect two 16-in/8-out stage interface boxes for I/O expansion,
Supports up to 78 inputs and 40 outputs.
Dante Support:
Direct external Dante box connection,
Dante signal input/output,
Multi-track recording.
Key Features:
MIC Input Gain Adjustment (smooth digital gain, scene-saving).
MIC Channel Linking (parity or AB linkage).
+48V Phantom Power (independent per channel, scene-saving).
Feedback Suppression for each MIC channel.
Channel Processing:
Limiter, noise gate, phase, high/low-pass filter, 5-band parametric EQ, delay, balance.
Fast Channel Parameter Copy.
Multi-function Menu, Mute, and Monitor per channel.
100mm Electric Faders (26 ALPS faders).
26-Channel TFT Display (real-time monitoring, Chinese naming, color customization).
Independent Fader Control for input, output, and effects.
User-Defined Fader Layers.
8 Customizable Physical Keys.
8 DCA Groups & 8 Mute Groups.
Integrated Feedback Suppressor.
Signal Generator (pink noise, white noise).
Real-Time RTA Spectrum (color editable).
Dual-System Data Backup.
Chinese Input Support for channel/scene editing.
Auto Mixing Function.
Talkback & MIDI Support.
AUX Output Settings (pre/post fader).
Output Channel Processing:
High/low-pass filter, 15-31 band GEQ, compressor, delay, phase.
USB Stereo Recording.
Built-In Sound Card (direct playback/recording from phone, iPad, MP3, PC).
8 Quick Scene Recall Modes, 100 scene storage, seamless switching, U disk import/export.
4 Independent DSP Effects with presets.
FX Foot Switch Interface.
12V Output for external lighting.
One-Click Factory Reset.
232 Central Control Support.
Multi-OS Control Software (iOS, Android, Windows).
Wired/Wireless Network Adjustment (via router).
