:Specifications

• .24 Gigabits (with PoE), supportIEEE 802.3af/atstandard, 10 Gigabit optical interface can beadapted to gigabit
• .Ultra-high switching capacity, support full portwire-speed forwarding performance
• .Weak Layer 3 access switch, support full port hardware Layer 3 wire-speed forwarding performance
• .High-performance low-power network processor, support for green Ethernet line sleep capability, low devicepower consumption
• .Support IPv4/IPv6 dual-stack platform, support RIP/OSPF/PIM and other routing protocols
• .Support VRRP/ERPS/MSTP/FlexLink/MonitorLink and other link redundancy and network redundancy protocols
• .Support ACL security filtering mechanism, provide MAC, IP, L4 port and port level security control functions
• .Support Ethernet OAM 802.3ag (CFM),802.3ah(EFM) and other Ethernet link detection mechanisms
• .Supports remote user authentication based on Tacacs+/Radius, and supports Local user authentication
• .Supports SP/WRR/SP+WRR priority algorithm to ensure the transmission of various priority traffic flows on demand
• .Support IPv4/IPv6 static routing function
• .Supports multi-port mirroring analysis and service flow-based image analysis
• .Support static and flexible QinQfunction
• .Support IPV4/6unicast routing in the policy, support flexible forwarding policy
• .Supports CLI command line management based on serial port, Telnet, and SSHv2 mode
• .Support RFC1213 SNMP network management
• .Supports configuration management based on WEB pages

Product Specifications

:Physical Interface

• .10 Gigabit optical port: 4*10 Gigabit optical ports, 10 Gigabit optical port adaptive connection Gigabit optical, type SFP/SFP+/LC
• .PoE ports: 24 Gigabit ports with PoE, support IEEE 802.3af/atstandard, type RJ45
• .Console port: manage serial port, used for command line management, type RS232

:Working environment

• .Operating temperature: -15C/~55C
• .Storage temperature: -40C/~70C
• .Relative humidity: 10%~90%, non-condensing

:Power consumption

• .Power supply specifications: single AC power supply, fixed 400W power supply
• .Input power: AC: input 90~264V, 47~67Hz
• .Power consumption of the whole machine: full load power consumption ≤ 400W, idle power consumption ≤ 25W

:Mechanical structure

• .Chassis shell: metal shell, air-cooled heat dissipation
• .Chassis size: dimensions (length * width * height) (mm) 440 * 270 * 44
• .Installation: Standard 19 inch 1U rack mount installation
